Solar Tracking System

Specification
The solar tracking system implements distributed actuation architecture, enabling each row to be independently controlled by its own motor with the tracking method “Astronomical algorithm + closed-loop control”. making the system accurate and reliable,real-time closed-loop feedback tracking angle, automatic tracking, without human intervention.
Tracking Structure Parameters
Tracking Technology
Dual-Portrait Horizontal flat single-axis tracking system
Maximum capacity per row
72KWp(3 or 4 Strings of 210 Type Module)
PV-Modules quantity per row
45PCS (2Px45) or 60PCS (2PX60)
Tracking range
±45°to ±60°
Tracking accuracy
±1°
Terrain Adaptability
10°north-south, east -west unlimited
Protection of wind speed
18m/s
Foundation form
Concrete (customizable all steel foundation)
Tracking Controller Parameters
Control system
MCU
Communication type
RS485 or wireless Zigbee
Night stow mode
Have
Self trouble checking
Function
Have
Overload prevention
Have
Backtracking algorithm
Have
System voltage
DC24
Drive System
Linear Motor
Power Acquisition Mode
External Supply/Self-Powered supply
Control algorithm
Astronomical Multi-point algorithm + closed loop（AI Control）
