Galvanised Double Ribbed Lintel

share
WeChat
Sina Weibo
QQ
QQ space
Douban
Baidu Post Bar
Spec Customized
Material Carton Steel
Brand TYNE
tdsteel2000@vip.126.com
Detail
Item
Lintel
Lintel
Flat bar Lintel
Flat bar Lintel
Main izes
100*100*6/7/8/9/10/12mm
150*100*6/7/8/9/10/12mm
85*7mm
75*10mm
Remarks
Any length as required
Any length as required
Any length as required
Any length as required
Length
Different lengths are available
Different lengths are available
Different lengths are available
Different lengths are available
Finish
Hot dip galvanized/Painted
Hot dip galvanized/Painted
Hot dip galvanized/Painted
Hot dip galvanized/Painted
Standard
AS/NZS 4680
AS/NZS 4680
AS/NZS 4680
AS/NZS 4680
Certificate
ISO9001:2008
ISO9001:2008
ISO9001:2008
ISO9001:2008


All of our lintel and T bar range include the following features and benefits:

1.Hot Dip Galvanized to AS/NZ 4680:2006.

2.R3 Durability Rating in accordance with AS/NZS 2699:2002.

3.Load Tested in accordance with AS/NZS 1170.1:2002.

4.Fully welded and not reliant upon composite action.

5.Other T Bar Sizes available. Please contact our sales department for more information6.Compliant with relevant Building Codes & Standards.

7.Full product warranty.8.Fully engineered.
